Overview
Product Summary
- Recommended for high-frequency usage (400 cycles per day)
- Made with two heavy duty concealed nylon bearings
- Recommended for use with a door closer
- Packed with fasteners for hollow metal and wood doors:
- Certified to ANSI/BHMA A156.1 for performance standards
- Meets ANSI/BHMA 156.7 for template hinge dimensions
- UL Classified for windstorm rated assemblies - R37965
- UL Listed, 3 hour fire doors
- Made from brass, 1040 steel, or 304 series stainless steel
- Electrification information:
Provides electric power transfer from the frame to the door in order to supply power to an electrified mortise or cylindrical lock, exit devices with electric latch retraction, and/or electric strikes (pairs of doors). Through-wire is rated 50 volts AC/DC at 3.5 amp continuous and 16 amp pulse. Maximum pulse 400 milliseconds. Ives through-wire hinges are fully compatible with 4 wire(TW4) and 8 wire (TW8) installations. Available CON option comes with the Allegion Connect 8-pin Connector which makes it easy to connect to other electrical consumption devices. - UL634 Listed
- Not available with security stud (SH) option
- Packaged one hinge per box with standard wood and machine screws
- Hinge is NRP as a standard
- High-quality brass ferrules and plastic tubing protect the wires
- Through-wire hinges cycle tested to ensure durability
Product Identifiers
,3CB1HWTW8412652
